Product Features:
For the recycling of waste plastics, the waste plastics need to be cleaned, dried, then melted and plasticized with the screw extruder of the plastic recycling granulator, extruded into strips, then cooled by cooling equipment, and finally cut with a pelletizer. These pellets are further processed into various plastic products through blow molding, injection molding, calendering and other processes.
HDPE/PP/PE/LDPE/LLDPE crushing material + PE/PP film recycling granulation production line (multifunctional soft and hard plastic) equipment has the following two advantages:
1. Both soft and hard plastics can be recycled. This fundamentally solves a major problem for many plastic recycling manufacturers. In the past, two production lines had to be used for the recycling of soft and hard plastics, which not only increased the purchase cost of equipment, but also At the same time, it also brings troubles to the floor space of the production workshop and reduces labor costs.
2. This machine has the characteristics of crushing, extruding and granulating equipment. When recycling soft plastics (ie films, woven bags, packaging bags), it does not need to be crushed separately, and can be recycled and granulated directly.
The Machine Layout:
1.Belt conveyor
2.Compactor
3.Single screw extruder machine
4.Hydraulic screen exhanger
5.Single screw extruder machine
6.Hydraulic screen exhanger
7.Vertical Water-ring die face cutting system
8.Water slot
9.Centrifugal dryer
10.Vibration
Main Parameter Data Sheet:
Model | Screw diameter(mm) | L/D | Capacity(kg/h) | Main motor power(kw) | compactor power(kw) | Line length(m) |
PP/PE-85 | 85 | 25-33 | 200-250 | 75 | 55 | 10 |
PP/PE-100 | 100 | 25-33 | 250-300 | 90 | 55 | 12 |
PP/PE-120 | 120 | 25-33 | 350-400 | 110 | 90 | 15 |
PP/PE-130 | 140 | 25-33 | 400-500 | 132 | 110 | 18 |
PP/PE-160 | 160 | 25-33 | 600-800 | 160 | 110 | 20 |
PP/PE-180 | 180 | 25-33 | 600-800 | 250 | 132 | 26 |
Types of Hydraulic Screen Changer:
 |  |
 |  |
Types pelletizer:
 |  |
 |  |
The Final Products:
 |  |
Packing &shiping
 |  |
Cetificate
Our Service:
1. We will provide all the machines for the complete production according to customer's requirements.
2. We will provide complete service for factory layout and other information to help customer to build the factory.
3. We will provide good service for machine installation and training, until the customers can run the machines and make stably production.
4. Except one year quality guarantee, we will provide after-sell service for all the life.
5. For long-term cooperation, we always provide good quality, good price and good service to customer.
