Plastic PET Flakes Crush Wash Dry Recycling Machine

Product Description

The production process of plastic PET flakes crush wash dry recycling machine, the key to recovering the original material from waste plastic is the removal rate of impurities. The content of impurities includes pollutants in the environment, other materials attached to the original plastic products, and heterogeneous substances.

The higher the purity, the more high-quality products can be produced, and the lower the manufacturing cost and production loss of its products. Pure recycled bottle flakes with total impurities below 100ppm produce the greatest production value for the production of high-grade raw materials.

Detailed process

1. The PET bottle is unpacked. After unpacking, according to the specific situation of the material, see if it is necessary to remove the impurities before stripping. Most domestic bottles are labelled (except for oil bottle labeling). The labeling machine can be used to efficiently remove the label of the bottle body.

2. The PET bottles enter the sorting platform to remove other impurities, variegated bottles and metals in the material.

3. Transport to the crusher for crushing. After crushing, the bottle cap (PP plastic) and the bottle flakes are separated. The water tank can effectively separate the bottle cap and the bottle flakes. The bottle cap is made of floating plastic and the bottle flakes are Submersible plastic

4. Enter the hot washing machine for hot washing, and put a certain proportion of caustic soda or cleaning agent to effectively remove dirt, oil and other impurities on the bottle flakes

5. The bottle flakes boiled at high temperature are washed by high-speed friction to remove the attachments on the surface

6. In the rinsing stage, rinse off the caustic soda and other impurities on the bottle

7. The bottle flakes have been cleaned, and finally dehydrated and packaged.

The product line main components

Main Machine Technical Parameter:

The Raw Materials:

The Final Products:
